Scanner,UHF RFID Reader Handheld PDA for Stock Inventory
HC-A08 Android Mobile Computer
HC-A08 serial products extend Handheld-Wireless product serials into Android OS 7.0 with 4G high speed network communication with pistol grip. Inside the compact handheld device, sealing level of IP65 water/dust proof, 1.5m/4.5ft drop survival, ergonomic design, over-molding structure, quick- charging technology, large built-in battery of 8100mAh, and 5.0 inch tough Gorilla Glass 3 9H screen are all equipped to ensure performance. Latest 1.3GHz quad-core processor 2GB RAM/16GB ROM and up to 32GB expansion are all designed to boost up experience level.
FEATURES
———————————————————————————————————————–
Extremely Stable Performance
Android 7.0 OS with memory of 2GB RAM/16GB ROM can provide the highly standard experience
High Speed Data Communication
Double insurance of 4G high Speed network and dual-frequency WIFI network can ensure the real-time data communication in different using environment;
Rugged Ergonomic, Over-molding Design with Extremely Stable Hardware Display
Over-molding, ergonomic hardware design and 5.0 inch tough Gorilla Glass 3 9H can satisfy most of the tough environment from different fields;
High Efficiency Operating Style
Mounted pistol grip with built-in battery of 8100mAh can ensure the high efficiency in outdoors environments;
High Accuracy and Long Reading Distance
Optional ThingMagic/R2000 UHF Reader can guarantee the high reading accuracy and long reading distance;
Highly Customized Structure
‘All-in-One’ hardware design conception can expand the hardware modules integration based on different project requirements, especially like UHF+HF, UHF+LF; HF+LF;
Quick-Charging
Quick-charging technology can provide the most efficient experience;
Perfect Service
Professional and skillful service involving the whole life cycle can guarantee the stability.
Technical Data:
|
SPECIFICATIONS |
||
|
PHYSICAL CHARACTERISTICS |
||
|
Dimension |
170mm(H)x85mm(W)x23mm(D)±2 mm |
|
|
Weight |
Net Weight :480g (including battery&wrist strap) |
|
|
Display |
5.0 inch Gorilla Glass 3 9H TFT-LCD(720×1280)touch screen with backlight |
|
|
Backlight |
LED backlight |
|
|
Keypads |
3 TP keys, 6 function keys, 4 side buttons |
|
|
Expansions |
2 PSAM, 1 SIM, 1 TF |
|
|
Battery |
Rechargeable li-ion polymer, 3.7V, 8100mAh |
|
|
PERFORMANCE CHARACTERSTICS |
||
|
CPU |
Quad A53 1.3GHz quad-core |
|
|
Operating System |
Android 7.0 |
|
|
Storage |
2GB RAM, 16GB ROM, MicroSD(max 32GB expansion) |
|
|
USER ENVIRONMENT |
||
|
Operating Temp. |
-20℃ to 50℃ |
|
|
Storage Temp. |
-20℃ to 70℃ |
|
|
Humidity |
5%RH to 95%RH(non-condensing) |
|
|
Drop Specifications |
5ft./1.5 m drop to concrete across the operating temperature range |
|
|
Sealing |
IP65, IEC compliance |
|
|
ESD |
15kv air discharge, ±8kv direct discharge |
|
|
DEVELOPMENT ENVIRONMENT |
||
|
SDK |
Hencodes Software Development Kit |
|
|
Language |
Java |
|
|
Environment |
Android Studio or Eclipse |
|
|
DATA COMMUNICATION |
||
|
WWAN |
TDD-LTE Band 38, 39, 40, 41; FDD-LTE Band 1, 2, 3, 4, 7,17, 20; WCDMA(850/1900/2100MHz); GSM/GPRS/Edge (850/900/1800/1900MHz); |
|
|
WLAN |
2.4GHz/5.8GHz Dual Frequency, IEEE 802.11 a/b/g/n |
|
|
WPAN |
Bluetooth Class v2.1+EDR, Bluetooth v3.0+HS, Bluetooth v4.0 |
|
|
GPS |
|
|
|
DATA CAPTUER |
||
|
BARCODE READER(OPTIONAL) |
||
|
1D barcode |
1D laser engine |
Symbol SE955 |
|
|
Symbologies |
All major 1D barcodes |
|
2D barcode |
2D CMOS Imager |
Honeywell N6603/Newland EM3396 |
|
|
Symbologies |
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Japan Postal, Dutch Postal. etc. |
|
COLOR CAMERA |
||
|
Resolution |
8.0 megapixel |
|
|
Lens |
Auto-focus with LED flash |
|
|
RFID READER(OPTIONAL) |
||
|
RFID LF |
Frequency |
125KHz/134.2KHz(FDX-B/HDX) |
|
|
Protocol |
ISO 11784&11785 |
|
|
R/W Range |
2cm to 10 cm |
|
RFID HF/NFC |
Frequency |
13.56MHz |
|
|
Protocol |
ISO 14443A&15693 |
|
|
R/W Range |
2cm to 8cm |
